ABB ACS580-01-106A-4
ABB ACS580-01-106A-4 is a wall-mounted ACS580 general-purpose drive in the 400 V class, rated at 55 kW and 106 A in frame R6 for pumps, fans, conveyors, and other standard industrial loads.
Broader comparison
At this size, the selection boundary is usually not “which ABB drive family is newer.” It is whether the machine is still a straightforward general-purpose duty in the ACS580 lane or has crossed into a control and option profile that really justifies ACS880.
Specifications
Product family
ABB ACS580-01
Exact model
ACS580-01-106A-4
Drive type
LV AC general-purpose wall-mounted drive
Output power, normal use
55 kW
Output current, normal use
106 A
Input voltage class
400 V class / 380-480 VAC
Input phase
Three-phase AC
Input frequency
50/60 Hz class
Protection class
IP21 / UL Type 1
Frame size
R6
Mounting
Wall-mounted cabinet installation
Motor control role
General-purpose speed and torque control for standard AC motors
EMC posture
ACS580-01 400 V class drive with EMC filtering in the configured product family
Common applications
Pumps, fans, conveyors, compressors, mixers, and process auxiliaries
