Panasonic MCDLN35SE
MCDLN35SE is a Panasonic MINAS A6S servo driver for 200 V single- or three-phase systems, rated at 750 W in C-frame for pulse-train position control without an integrated safety function.
Broader comparison
Use the interface type as the first filter. MCDLN35SE is a pulse-train A6S drive, so comparisons should stay within compatible command architectures before looking at wattage or frame size.
Specifications
Product family
Panasonic MINAS A6S servo driver
Control architecture
Position control type, pulse-train only, incremental-system-only
Safety function
None integrated
Rated motor output
750 W
Main circuit input
Single-/three-phase 200 to 240 VAC, 50/60 Hz
Control circuit input
Single-phase 200 to 240 VAC, 50/60 Hz
Output current
22 A
Frequency response
3.2 kHz
Frame size
C-Frame
Dimensions (W x H x D)
65 x 150 x 170 mm
Mass
1.6 kg
Encoder handling
23-bit encoder hardware; this A6SE variant is used as incremental system only
Parallel I/O
10 general-purpose inputs, 6 general-purpose outputs, 2 analog monitor outputs
Pulse interface
2 pulse inputs and 4 pulse outputs
Service interface
USB
Regeneration
External regenerative resistor only
